Building an Observability Stack with Prometheus and Grafana

Most teams don’t have a metrics problem — they have a too many dashboards nobody looks at problem. This is the minimal setup we use to go from “no visibility” to “useful alerts and three dashboards people actually open during an incident.”

Prometheus v2.51 Grafana v10.4

Scrape config

Prometheus pulls metrics on an interval rather than receiving pushes, which keeps the failure mode simple: if a target stops responding, you get gaps, not silent data loss.

1
2
3
4
5

scrape_configs:
  - job_name: 'api'
    scrape_interval: 15s
    static_configs:
      - targets: ['api-1:9090', 'api-2:9090']

Querying the same thing two ways

PromQL and Grafana’s query builder both end up expressing the same question — “what’s our p99 latency over the last 5 minutes” — just with different syntax depending on where you’re working:

1
2
3

histogram_quantile(0.99,
  rate(http_request_duration_seconds_bucket[5m])
)

 1
 2
 3
 4
 5
 6
 7
 8
 9
10

- alert: HighP99Latency
  expr: |
    histogram_quantile(0.99,
      rate(http_request_duration_seconds_bucket[5m])
    ) > 0.5
  for: 10m
  labels:
    severity: warning
  annotations:
    summary: "p99 latency above 500ms for 10 minutes"

The three dashboards that earn their keep

Everything else is useful for deep-dives, but these are the ones worth pulling up during an active incident:

1. Golden signals — latency, traffic, errors, saturation, per service. If this doesn’t tell you where to look next, the next dashboard won’t either.
2. Deploy correlation — a vertical marker on every graph for each deploy. Most “mystery regressions” are a deploy that happened 20 minutes before someone noticed.
3. Dependency health — the two or three external services and datastores that, if slow, make everything downstream look broken.
